Monitor Specs:
- Resolution 1920 x 1200 pixels
- 2200 nits
- Lemo 2-pin power input to D-tap (12-34V)
- Gorilla Glass
- Colour Depth: 10-bit processing
- Contrast: 1200:1
- Inputs: 2x SDI and HDMI, USB
- Outputs: SDI and HDMI
- Gamut: 100% Rec 709
- 12.4 x 21.29 x 2.87 cm
Software
Pixel Zoom – 2x & 4x with smooth pan via joystick
Frame Guides – Yes
DSLR Scale – Canon & Nikon
Custom Scale – Yes
Anamorphic De-Squeeze – Yes: 1.33x, 1.66x, 2.0x
Image Rotate – Yes
Image Flip – Automatic or Manual Control
Cross Conversion – Yes: HDMI > SDI & SDI > HDMI
Focus Assist – User Adjustable Colour Style and Intensity
Peaking – User Adjustable Intensity
False Colour – Spectrum, Arri Style and Fully User Customisable
Zebra – Dual – User Configurable
Waveform – Luma & RGB Style, Fully User Customisable w/ Region of Interest Highlighting
Vector-scope – Yes
PIP – No
RGB Parade – Fully User Customisable
Histogram – Luma & RGB Style
Horizon Indicator – No
Image Capture – With Dedicated Button and Image Gallery
Custom LUTS – Loadable as Looks on Pages or as Systemwide Colour Calibration via the settings menu
LUT Creation – No
LUT Downstream – Available on SDI1 or HDMI out, Applied on Output Preview Page
LUT Import – Via SD Card or USB Storage Device
Overlay – Opacity Slider and Blink Setting
Blue Only – No
Audio Meters – HDMI & SDI up to 8 channel
Teradek Specs
- zero delay
